Open UP Specifications
| U.P. | U.P.P.E.R. | |
|---|---|---|
| Frameset Price (USD, excl. sales tax) | $3,200 | $4,500 |
| Frame-only weight size M, ±3% | 1,040g | 880g |
| Fork-only weight,, ±3% | 390g | 370g |
| Sizes | S/M/L/XL | S/M/L/XL |
| Color | Green, Blue, RTP | Matte Black, RTP |
| RTP( Ready-to-paint) |
A clearcoat is not needed for UV protection but recommended to protect against scratches and wear. Some customers leave the frame bare.
|
|
| BB standard |
BB386EVO pressfit 86.5x46mm BB shell
|
|
| Recommended groupsets |
For serious gravel and off-road (on any brand of bike), we recommend a rear derailleur with a clutch or cage damper (Shimano GRX (1x & 2x), SRAM Force AXS & Red AXS (1x & 2x), SRAM Apex1, Rival1, Force1)
|
|
| Shimano crank fit |
All road cranks
|
|
| SRAM crank fit |
All GXP road, all DUB road, Force 1 BB30
|
|
| Powercrank fit |
Detailed information here
|
|
| Front derailleur mount |
Bolt-on, removable
|
|
| Recommended ring shape |
Flat
|
|
| Maximum 1x ring size |
Clearance depends on crank & chainring model. 2mm space is required. For most current generation cranks, the following applies: 50t (flat ring), 46t (SRAM offset ring)
|
|
| Maximum 2x ring size |
Clearance depends on crank & chainring model. 2mm space is required. For most current generation cranks, the following applies:50t (outer ring), 36t (inner ring)
|
|
| Rear thru-axle |
142x12mm superlight Carbon-Ti X-12
|
|
| Front thru-axle |
100x12mm superlight Carbon-Ti X-12
|
|
| Front disc rotor size |
160mm only
|
|
| Front brake caliper mount |
Smartmount 160 system attaches flatmount caliper, without adaptor, for 160mm rotors
|
|
| Front brake bolts SRAM |
37mm “REAR” brake bolts for 30mm “chainstay” (SRAM part# 00.5318.005.008)
|
|
| Front brake bolts Shimano |
43.2mm “REAR” brake bolts for 30mm “chainstay” (Shimano part# Y8N208030)
|
|
| Rear disc rotor size |
140mm or 160mm
|
|
| Rear brake 140mm mount |
Direct mount
|
|
| Rear brake 160mm mount |
Use adaptor for SRAM (00.5318.018.001) or Shimano (ISMMAR160DDA)
|
|
| Rear brake bolts SRAM (140mm & 160mm disc) |
2x 27mm (SRAM part# 00.5318.005.004)
|
|
| Rear brake bolts Shimano (140mm & 160mm disc) |
2x 33.2mm (Shimano part# Y8N208010)
|
|
| MultiStop internal system |
1x & 2x mechanical, Di2, eTap (eTap only included in U.P.P.E.R. frameset)
|
|
| Headset |
Integrated IS42/28.6 | IS52/40
|
|
| Seatpost |
27.2mm diameter, standard set-up zero-offset
|
|
| Cage mounts |
Seattube, downtube, under downtube
|
|
| TT bag mount system |
100mm front-post-to-headset-edge
|
|
